GMod and SFM To XNALara tutorial by user619 GMod and SFM To XNALara tutorial by user619
Watch this Video: www.youtube.com/watch?v=J_Rsdo…
and Download these Tools: www.mediafire.com/file/8eu1pm3…

First get your files from steam workshop
For GMod you must subscribe to the mod in order to use GmadExtractor
Use GmadExtractor to open the gma file and extract the folders {SFM has the same folders you just wont use GmadExtractor}
Then load up Noesis and find and select the .mdl file and right click then export
And export as a psk file then run your 3ds max { I have only used 3ds max 2012} then click max script at the top then run script and open ActorXImporter.ms
A window wll pop up and click import psk and import the psk file you extracted from Noesis it may tell you to find the textures or you can skip that
When done loading run the XnaLara Converter.ms script and a window will pop up and click export and export it as model.mesh.ascii
The next thing to do is to convert the textures use VTFEdit.exe find your textures which are located in the materials folder and they will be in a .vtf format
Use VTFEdit.exe to export them into png or tga format

If you have transparent textures just open them in paint.net  its a software and click file then save as and save it as a .dds file and
select X8R8G8B8 and it will fix the transparency bug but make sure you reload it in to Paint.net and save it as a .dds file again and then select DXT1

Then send your textures to were your model.mesh.ascii file is and load XNALara and click Modify then Load Genric item then click your model.mesh.ascii file
Now your model should show up. Next is to texture it if you have not already click Modify then martial editor
When done editing textures click Modify then Save genericitem and just click ok and thats it

The only problem I have encountered is the eyes having broken uvs.
This may or may not happen for you but thats the only bug I have had maybe someone can tell me why that happens.

Make sure to share the models you convert for XNALara with everyone else :)
Add a Comment:

:iconsohdakii:
sohdakii Featured By Owner 6 days ago
i dont get it :U
Reply
:iconuser619:
user619 Featured By Owner 5 days ago
What part do you not get?
Reply
:iconxnafreak:
XnaFreak Featured By Owner Sep 17, 2018
It is easily possible to convert MDL (GMod) or SMD to XNALara:

- If it is a MDL file, then use first Crowbar to convert it to SMD
copy all model data files .smd (geometry), all .vmt (Valve Material Type) and all .vtf  (Valve Texture Files)  in a new folder.
- Open the SMD file with smd2xps and you get directly the XNALara generic_item.mesh.ascii file.
Reply
:iconventura30:
ventura30 Featured By Owner Aug 3, 2018
man I did what you said But ... my pc does not open sfm and GMod texture exporter fuck I would like to ask you a favor I was going to convert from gmod to xnalara the nude coach You can not convert and post to download? I'm trying to make the programs run but my pc is slow on xnalara!

Reply
:iconuser619:
user619 Featured By Owner Aug 3, 2018
If you can't run xnalara then why do you want to convert a model to xnalara?
Also I made this tutorial so people don't ask me to convert a sfm or gmod model to xnalara.
Reply
:iconvarmaekir:
Varmaekir Featured By Owner Jul 13, 2018
Does it automatically assign bones to the converted model?
Reply
:iconuser619:
user619 Featured By Owner Jul 13, 2018
Yes this tutorial works perfectly all the time for me.
Reply
:iconvarmaekir:
Varmaekir Featured By Owner Jul 14, 2018
Thanks. I've tried it, and managed to port a SFM model to XNALara. However, the bones are messed up. Can't even rotate an arm properly
Reply
:iconuser619:
user619 Featured By Owner Jul 14, 2018
The model may have messed up bones.
Which sfm model are you using?
I want to see if I will have the same results.
Reply
:iconhatredboy:
Hatredboy Featured By Owner Jul 13, 2018  Hobbyist Digital Artist
Have you ever tried that before and success yet?
Reply
:iconuser619:
user619 Featured By Owner Jul 13, 2018
yes have you tried following this tutorial?
This is how I convert from gmod and sfm to xnalara.
Reply
:iconhatredboy:
Hatredboy Featured By Owner Jul 19, 2018  Hobbyist Digital Artist
Well,I want to try this steamcommunity.com/sharedfiles… but when I open noeisis and check the folder of this I subscribled,they're spit parts and all whites with no textures...
Reply
:iconuser619:
user619 Featured By Owner Jul 19, 2018
I am not sure about stages. They will be in parts they are only put together in sfm also you would have to manually add the textures.
Try to export it to obj file and move them into the right place then add the textures.
Reply
:iconhatredboy:
Hatredboy Featured By Owner Jul 19, 2018  Hobbyist Digital Artist
Okay.
Reply
:iconbatmite128:
Batmite128 Featured By Owner Jun 17, 2018  Hobbyist General Artist
What about vise versa
Reply
:iconuser619:
user619 Featured By Owner Jun 18, 2018
I don't know how to do that.

Reply
