After Sunset



The image you see here is really only half the story.  See the video below!  This design has been cut into chalkboard with a specially designed industrial laser art system:…

The piece is called After Sunset.  I made the artwork in Illustrator and have been working on the design and process for over a year.  It’s a collage of all sorts of things very much in the spirit of M.C. Escher.  Some of the patterns I found online, some are random, some are mathematical and at least one is religious in nature.  Others are borrowed from famous paintings etc.  There’s even a little hidden guy waving at you.

The macro pattern is the Golden Ratio found all over nature.  (…)

The substrate is actually a cut of wood composite with a finish of standard chalkboard paint.  The laser system was specially designed by LasX for artistic works such as this.  The piece is about 1 meter wide.

The file was exported directly from Illustrator as a PDF and loaded into LasX’s new Lightguide v5 Laser Control Software.  The real-time beam control was performed by LasX’s Proton laser controller - the beam's position is updated 100K times per second by the Proton controller.   This control platform is able to consume all the PDF layer data and can work with layers containing grey-scale images as well as vectors/paths.  The source PDF file contains over 70K vertices to define the vectors and the Lightguide v5 CAD engine loads it easily.  This is a big deal because LasX' competitors’ CAD software would fall to its knees trying to open a file with so much vector data.

In the first part of the video the laser is “raster” processing.  Raster processing is the laser equivalent of the old school ink-jet printer style of paper printing.  Here the beam is sent left and right across the material at a speed of 20 meters per second at a vertical repeat spacing of one pass per pixel in the image.  The grey level in the image is mapped to the laser’s power output on the fly.  This is how the chalkboard yields different levels of grey – we’re damaging the paint with just the right amount a power to get the affect.  Fortunately, the Lightguide v5 software running with our Proton laser controller affords us such control.  Parameters like laser beam speed, focus spot size and lines per inch are critical here.

The second part of the video shows the software “vector” processing the piece.  In this mode the laser beam follows the vectors defined in the PDF file.  The geometry is perfectly aligned with the raster part of the image.  A beam speed of 6 meters per second was shown.  During this process the laser is outputting nearly 1500 watts of power.  This causes the cuts to go through the paint and into the wood behind it – leaving an orange and brown color. The reason the vectors follow such a strange order across the piece is because a simple “proximity sort” was performed in the Lightguide v5 software before processing.
