F-35X HELLCAT gi-joe by bagera3005 F-35X HELLCAT gi-joe by bagera3005
Lockheed Grumman F-35X HELLCAT gi-joe

Specifications F-35x

General characteristics

* Crew: 1
* Length: 55.4 ft (16.76 m)
* Wingspan: 41 ft[nb 1] (12.7 m)
* Height: 14.4 ft[nb 2] (4.39 m)
* Wing area: 460 ft[86] (42.7 m)
* Empty weight: 29,300 lb (13,300 kg)
* Loaded weight: 49,540 lb[52][nb 3][206] (22,470 kg)
* Max takeoff weight: 70,000 lb[nb 4] (31,800 kg)
* Powerplant: 1 General Electric F222 afterburning turbofan
o Dry thrust: 28,000 lbf[207][nb 5] (125 kN)
o Thrust with afterburner: 43,000 lbf[207][208] (191 kN)
* Internal fuel capacity: 18,480 lb (8,382 kg)[nb 6]

Performance

* Maximum speed: Mach 1.6+[81] (1,200 mph, 1,930 km/h)
* Range: 1,200 nmi (2,220 km) on internal fuel
* Combat radius: over 590 nmi[nb 7] (1,090 km) on internal fuel[209]
* Service ceiling: 60,000 ft[210] (18,288 m)
* Rate of climb: classified (not publicly available)
* Wing loading: 91.4 lb/ft (446 kg/m)
* Thrust/weight:
o With full fuel: 0.87

Armament

* Guns: 1 General Dynamics GAU-22/A Equalizer 25 mm (0.984 in) 4-barreled gatling cannon, internally mounted with 180 rounds[nb 9][81]
* Hardpoints: 6 external pylons on wings with a capacity of 15,000 lb (6,800 kg)[81][86] and 2 internal bays with 2 pylons each[86] for a total weapons payload of 18,000 lb (8,100 kg)[53] and provisions to carry combinations of:
o Missiles:
+ Air-to-air: AIM-120 AMRAAM, AIM-132 ASRAAM, AIM-9X Sidewinder, IRIS-T, Joint Dual Role Air Dominance Missile (JDRADM) (after 2020)[211]
+ Air-to-ground: AGM-154 JSOW, AGM-158 JASSM[92]
o Bombs:
+ Mark 84, Mark 83 and Mark 82 GP bombs
+ Mk.20 Rockeye II cluster bomb
+ Wind Corrected Munitions Dispenser capable
+ Paveway-series laser-guided bombs
+ Small Diameter Bomb (SDB)
+ JDAM-series
+ B61 nuclear bomb[212]

Avionics

* Northrop Grumman Electronic Systems AN/APG-81 AESA radar

o With 50% fuel: 1.07
* g-Limits: 9 g[nb 8]

Titanium Rain based design
