Ragnarok-class Resupply/Tender by Afterskies Ragnarok-class Resupply/Tender by Afterskies
Class: AOE-AS, (Fast Combat Supply Ship, Sub-Tender)
Hull Style: Monohull
Length: 768 feet
Width: 112 feet
Height: 160 feet (from waterline) 196 feet (with draft)
Draft: 36 feet*
Tonnage: 26,807†
Speed: 31 knots (35 knots for Non-Nuclear Variant)
Aircraft: 3†
Boats: 2 RHIBS
Ship's Force: 910†
Air Wing: 36†

Defenses:
2 30mm Shield CIWS
8 25mm Mk3 Rapier Defense Autocannons
10 .50-cal Dagger ROADS
2 NRAM Longsword Missile Launhers
40 Active Anti-Torpedo Decoy-Explosives
3 Active SONAR Decoys, towed
10 .50-cal Machine gun posts
Full Command Electronic Warfare & Deterrence Suite

Power & Propulsion
Power Source: (1) D2H3 800Mw PWR
Back up Source: (2) 3Mw Diesel Generators
Battery Back up: 24 Hour life, 8 for propulsion
Propulsion: 2 Asimov Engineering CV-3 Motor-Propulsors, Fixed (Variable Direction Nacelle)
Secondary Propulsion: 4 Extending Maneuvering Azipods

Air: 2 Helicopter-hangar bay

Support:
2 Small Cranes
1 Large Crane
6 Resupply Lines
4 Resupply Stations
†Indicates Nominal Value
