E-53 Angelhawk AWACS by Afterskies E-53 Angelhawk AWACS by Afterskies
  • Crew: 11 (two Pilots, Navigator, Radar Officer, Flight Engineer, Electronic Warfare Officer, three Radar Operators, Combat Information Center Officer, Air Control Officer)
  • Length: 99 ft 2 in (30.2 m)
  • Wingspan: 137 ft (41.8 m)
  • Wing Configuration: Shoulder, Straight, High-Aspect Ratio, Tapered, Dihedral
  • Rear Stabilizer Configuration: V-Tail
  • Height: 40 ft (12.2 m)
  • Max Takeoff Weight: 162,000 lb (73,481 kg)
  • Powerplant: 4 × Asimov TP-49 Turboprops, 5,020 shp (3,689 kW) each
  • Propellers: 4 propeller, 8 bladed
    • Propeller diameter: 13.6 ft (4.1 m)

Performance

  • Maximum Speed: 330 knots (380 mph, 611 km/h) at 20,000 ft (6,060 m)
  • Cruise Speed: 300 kts (345 mph, 556 km/h)
  • Range: 2,950 nmi (3394 mi, 5463 km)
  • Service Cieling: 34,000 ft
  • Rate of Climb: 1,850 ft/min (564 m/min)
  • Takeoff distance: 3,400 ft

Avionics
AN/APN-02A AESA:

  • Look Up Mode Range: 350 miles
  • Look Down Mode Range: 180 miles against small, Maritime Targets 240 miles against large Maritime Targets
AN/APN-91 Weather and Navigational Radar Suite
