AL-53 Revenant by Afterskies AL-53 Revenant by Afterskies
  • Crew: 8 (two Pilots, Navigator, Fire control officer, Electronic warfare officer, Flight engineer, Sensors Operator, Combat Directions Officer)
  • Length: 99 ft 2 in (30.2 m)
  • Wingspan: 137 ft (41.8 m)
  • Wing Configuration: Shoulder, Straight, High-Aspect Ratio, Tapered, Dihedral
  • Rear Stabilizer Configuration: V-Tail
  • Height: 40 ft (12.2 m)
  • Max Takeoff Weight: 162,000 lb (73,481 kg)
  • Powerplant: 4 × Asimov TP-49 Turboprops, 5,020 shp (3,689 kW) each
  • Propellers: 4 propeller, 8 bladed
    • Propeller diameter: 13.6 ft (4.1 m)

Armament

  • Internal: 300KW Laser

Performance

  • Maximum Speed: 290 knots (333 mph, 537 km/h) at 20,000 ft (6,060 m)
  • Cruise Speed: 260 knots (299 mph, 481 km/h)
  • Range: 2,660 nmi (3061 mi, 4926 km)
  • Service Cieling: 34,000 ft
  • Rate of Climb: 1,850 ft/min (564 m/min)
  • Takeoff distance: 3,400 ft
Avionics
AN/APQ-2 Multi-Mission Surface Search and Attack Radar
AN/APN-91 Weather and Navigational Radar Suite
AN/AAQ-9 Multispectral Sensor System
